MTL INSTRUMENTS MTL 2213 SWITCH/PROXIMITY DETECTOR RELAY

MTL Instruments MTL 2213 Switch/Proximity Detector Relay 250V 14MA

mtl instruments mtl 2213

mtl instruments pvt. ltd.

mtl

mtl 2213

3-channel

switch/proximity detector relay

 [eexia] iic

baseefa no. ex 88b2114

bs 5501: part 7: 1977

en50 020

um= 250v

umax=: out= 10,5v

imax: out= 14ma

maximum ambient temperature 60°c

cl i, div.1, gps. a,b,c,d;

cl ii, div.1, gps. e,f,g;

cl iii, div.1

vm= 250v r.m.s.

supply: 24v dc or 120v ac or 240v ac, 5va

contact rating:

250v ac max, 5a max, 100va

250v ac/dc max, 5a max, 100w

1 pcs available

weight 0.250 kg

SKU NO.: B1183
